Visualizations: Gantt

TopLeft can show data from your PSA on Gantt charts. Gantt charts are a project management tool that shows work based on the scheduled start and end dates of the work.

A Gantt chart of one project's tickets by phase, under a header showing 61% complete, 4 of 11 tickets open, 39.5 of 65 budget hours used and the scheduled dates, with dependency arrows, an over-budget task in red and the today line

When the Gantt shows a single project, a header above it shows the project's percent complete, open and total tickets, budget hours used against the budget, and its scheduled dates.

Gantt charts have two parts:

  • On the left, a tabular view with columns with various details of the records.
  • On the right, a visual taskbar view where a horizontal bar represents the period of time the task is scheduled to be worked.

Gantt charts show predecessor/successor relations between records.

To update general details of a record, click its taskbar to open the editing tool.

Updating Dates

To move a task to a different date, but leave its duration unchanged, drag the taskbar to the left or right.

To change the duration of a task, drag the right side of the taskbar to the left or right.

TopLeft updates the dates of a record in your PSA immediately.

Other Functions

Use the toolbar to exercise other functions:

The Gantt toolbar: Zoom in, Zoom out, Zoom to fit, Show today, Expand all, Collapse all, and PDF export

  • Zoom in
  • Zoom out
  • Zoom to fit: Adjusts the zoom level and position such that no horizontal scrolling is needed to see any records. Keep in mind some records may only become visible when you scroll vertically.
  • Show today: turns on a line at the position of today in the taskbar section
  • Expand/collapse all
  • Export to PDF

Updated October 6, 2026
